Raifu TD Series Power Frequency Compressor
Single-phase 220V fixed-speed screw compressor with integrated tank for workshops and small industries.
- Compatible with domestic single-phase 220V power for ease of installation
- Space-saving integrated configuration of screw compressor and 60L receiver tank
- Optimized oil lubrication system to minimize mechanical wear and friction
Description
The Raifu TD Series air compressor features reliable Power Frequency (fixed-speed) technology with the advantage of an economical initial investment. Based on the actual TD2.2G-9 model data, this system is powered by a 2.2 kW (3 HP) electric motor designed to operate on single-phase 220V grids, making it highly versatile for automotive workshops or small industries without 3-phase power access. This lubricated direct-driven unit comes equipped with an integrated 60-liter receiver tank and a quiet air-cooling system, delivering a constant and clean air flow of 0.3 m3/min to support industrial pneumatic tools.
Technical Models & Specifications
The Raifu TD Series Power Frequency Compressor is available in multiple models each with its own technical specifications. Select a model below to view its complete parameters.
| Parameter | Value |
|---|---|
| Frequency Inverter | Seener Single Frequency Inverter |
| Air End Model | DLG7 |
| Motor Parameter | 7.5/3000 kW/rpm |
| Discharge Pressure | 7 bar |
| Rated Flow Rate | 1.16 m³/min |
| Overall Dimensions | 765 × 635 × 950 mm |
| Weight | 120 kg |
| Noise | ≤70 dB |
| Outlet Pipe Diameter | G1/2 |
Technical Features
Key capabilities and technical highlights that define this product's performance and reliability across industrial, automotive, and workshop applications.
